101mm Single Glazed
101mm Single Glazed
The McArthur Evo Centre Pocket Glazing System is the most popular and flexible of the Alspec® Commercial range. Available in two frame depths, 101.6mm and 150mm x 44.4mm. Ideal for shopfront use, it is widely favoured by architects and designers for a multitude of applications.
With it’s straight cuts and centre pocket glazing the McArthur not only looks good, but is easy to fabricate and easy to install. McArthur is suitable for a range of glass thicknesses with self draining sub sills that solve water leakage problems. The McArthur also provides a seamless interface with Alspec’s extensive product offer.
Latest projects
Recent works
Explore our latest projects showcasing precision, craftsmanship, and modern design.
From residential homes to large-scale commercial developments, each build reflects our commitment to quality and Australian excellence.
Key Features
- Sharp unbroken lines
- Centre glazed
- Robust frame
- Excellent weathering performance
- 101.6mm and 150mm x 44.5mm framing system
- 19mm glazing pocket accepts up to 14.5mm single glazed
- Colour coded glazing wedges for ease of identification
- Easily adapts to Alspec’s awnings and hinged doors
Technical Specifications
Frame Dimensions
| Option 1 | 101.6 x 44.5mm |
| Option 2 | 150 x 44.5mm |
Recommended Sizes
| Maximum Recommended Sizes | 101.6mm Frame | 150mm Frame |
|---|---|---|
| Height | 4200mm | 5100mm |
| Width | 2200mm | 2400mm |
Glazing Details (both)
| Glass Position | Centre |
| Single Glazed | 6 – 14.5mm |
Product Performance
| Maximum Product Performance | 101.6mm Frame | 150mm Frame |
|---|---|---|
| SLS (Pa) | 3000 | 3000 |
| ULS (Pa) | 7200 | 7400 |
| Water (Pa) | 1000 | 900 |
Acoustic Performance(both)
| Glass Type | Rw (C; Ctr) |
| 6.38mm Laminate | 32 (-1,-2) dB |
