50 mm Double Glazed
50 mm Double Glazed Window Framing
Upgrade your home or commercial space with high-performance 50 mm Double Glazed Window Framing — engineered for energy efficiency, structural integrity, and modern aesthetics. Ideal for new builds and retrofits, this framing system is optimized for thermal insulation and acoustic performance, while supporting a sleek architectural design.
Why Choose 50 mm Double Glazed Framing?
Superior Insulation
Double glazing with 50 mm framing significantly reduces heat transfer and improves indoor comfort.
Energy Efficiency
Lowers heating and cooling costs by maintaining consistent internal temperatures.
Sound Reduction
Minimize outside noise, ideal for homes near roads or urban areas.
Durability
Made from corrosion-resistant aluminium or uPVC profiles for long-lasting performance.
Customizable Design
Choose from various colours, finishes, and glazing options to match your style.
Technical Specifications
| Specification | Details |
|---|---|
| Frame Width | 50 mm |
| Glazing Type | Double Glazed (Standard: 4/16/4; Optional: 6/12/6, Low-E, etc.) |
| Thermal Break | Yes (Polyamide or similar material) |
| U-Value (W/m²·K) | 1.8 – 2.5 (dependent on glass specification) |
| Sound Insulation | Up to 40 dB (Rw) |
| Material Options | Aluminium, uPVC, Composite |
| Glass Thickness Supported | 20 mm – 32 mm |
| Air & Water Tightness | EN 12207 (Class 4) / EN 12208 (Class E1050) |
| Wind Load Resistance | Up to 2000 Pa (Tested per EN 12210) |
| Finish Options | Powder-coated (RAL colours), Anodized, Woodgrain |
| Hardware Compatibility | Standard multi-point locking, tilt-and-turn, or sliding gear |
| Installation Method | Surface mounted or concealed frame |
